Product Details

Condition:New	Place of Origin:China
Type:Powered Pallet Truck	Power Souce:AC Motor
Max. Lifting Height:3000MM	Min. Lifting Height:115MM
Fork Length:920MM	Fork Width:120MM
Overall Dimensions:215010901995MM	Certification:CE,ISO9001,EPA
Warranty:1 Year	After-sales Service Provided:Free Spare Parts
Weight:3000KG	Lift height:3000-5000mm
Mast:2stage /3stage	Product Name:1-1.8tons diesel forklift/2000-3600Lbs counterbalance forklift
Drive Motor:8w	Load Center:500 MM
Brand:SAFER	Turning radius:1950mm
Controller:Curtis AC Controller	Travel speed:15km/h

Product Description

Specifications:

Load (kg)	1000/1500
Lifting height (mm)	3000
Frame static height (mm)	2050/2100
After lifting the total height (mm)	3700
Load center distance (mm)	500
Wheelbase (mm)	1400
Turning radius (mm)	1750/1940
Fork size (forging) mm	100(920/10701220)*30
Driving method	Sitting and driving
Drive form	electric
Braking method	Electromagnetic brake
Battery (V/AH)	DC50/220AH*4P
Total Weight(KG)	1800*2800

Characteristics:

1.Side-put lifting cylinders and chains offer Wide-view visibility.

2.AC Variable-frqeuency speed control technology, greatly improved the reliability and safety.

3.Advanced H-drive axle, low center of gravity design, with stable turning.

4.With regenerative braking system, ramp soft staring, reverse braking system and other protection settings. Improve the safety under the hazardous environments.

5.Charger connection and emergency switch have an inter-lock system, safe for charging.

6.Special explosion-proof sealed VBS batteries conform to UK BS directive.

7.With anti-friction flameproof brake plate.

8.With alloy copper plated truck back body and forks.

Our Service

Pre-Sales Service

* Inquiry and consulting support.

* 24 hrs online service.

* View our Factory.

After-Sales Service

* Training how to instal the machine, training how to use the machine.

* Engineers available to service machinery overseas.
